Benchmarking MoodleBox on different Raspberry Pi models

(Last edited 2020-05-14 18:58 UTC)

Raspbian version : Raspbian GNU/Linux 10 (buster)
Moodle release : 3.8 (Build: 20191118)
MoodleBox version : 3.5.0 (2019-11-18)
MoodleBox plugin version : 2.4.2 (2019100700)
Kernel version : Linux 4.19.75-v7l armv7l
Moodle Benchmark plug-in version : v1.3.0 (2019083101)
SD card : SanDisk Ultra 16GB microSDHC I

# Item Accpt. limit Crit. limit RPi 3A+ RPi 3B RPi 3B+ RPi 4B
1 Moodle loading time 0.5 0.8 0.020 0.022 0.024 0.025
2 Processor processing speed 0.5 0.8 0.644 0.751 0.644 0.963
3 Reading file performance 0.5 0.8 0.045 0.051 0.044 0.046
4 Writing file performance 1.0 1.25 0.206 0.240 0.204 0.201
5 Reading course performance 0.75 1.0 0.114 0.147 0.127 0.077
6 Writing course performance 1.0 1.25 0.109 0.119 0.123 0.068
7 Database performance (#1) 0.5 0.7 0.021 0.025 0.025 0.015
8 Database performance (#2) 0.3 0.5 0.047 0.059 0.048 0.033
9 Login time performance 0.3 0.8 0.109 0.007 0.016 0.080
10 Login time performance 0.3 0.8 0.158 0.016 0.018 0.096
Total time 5.65 6.7 1.473 1.437 1.273 1.628
Score (points) 148 144 128 161

In all three cases the following warning was printed:

Watch out! Your Moodle performance is not optimal.

The processor seems too slow. Check that your hardware configuration is high enough to run Moodle.

# Item Description
1 Moodle loading time Load the "config.php" configuration file
2 Processor processing speed Call a PHP function with a loop to check the processor speed
3 Reading file performance Read a file multiple times to check the reading speed of the Moodle temporary folder
4 Writing file performance Write a file multiple times to check the writing speed of the Moodle temporary folder
5 Reading course performance Read a course multiple times to check the reading speed of the database
6 Writing course performance Write a course multiple times to check the writing speed of the database
7 Database performance (#1) Run a complex SQL query to check the speed of the database
8 Database performance (#2) Run a complex SQL query to check the speed of the database
9 Login time performance for the guest account Check the loading time of the guest account login page
10 Login time performance for a fake user account Check the loading time of a fake user account login page


PHP and DBMS compatibility of major Moodle releases

In the Moodle community forums we get a non-ending stream of requests from people having trouble in marching old Moodle installations to newer and supported realeases. Things break easily since along the path the system requirements have been evolving too. The following table summarizes their dependencies. (Last edited 2023-12-26 17:30 UTC)

Moodle rel. From rel. PHP MySQL PgSQL MariaDB
min. max. min. max. min. max. min. max.
1.6[1] 1.0 4.3.0 5.6 4.1.16 ? 8.0 - -
1.9[2] 1.6 4.3.0 5.6 4.1.16 5.7? 8.0 - -
2.2[3] 1.9 5.3.2 5.6 5.0.25 5.7? 8.3 - -
2.4 2.2 5.3.2 5.6 5.1.33 5.7? 8.3 - -
2.7 (LTS) 2.2 5.4.4 5.6 5.5.31 5.7? 9.1 5.5.31 10.2
3.0 2.2 5.4.4 7.0 5.5.31 5.7? 9.1 5.5.31 10.2
3.1 (LTS) 2.7 5.4.4 7.0 5.5.31 5.7 9.1 5.5.31 10.2
3.2 2.7 5.6.5 7.1 5.5.31 5.7 9.1 ? 5.5.31 10.2
3.3 2.7 5.6.5 7.1 5.5.31 5.7 9.3 5.5.31 10.2
3.4 3.0 7.0 7.1 5.5.31 5.7 9.3 5.5.31 10.2
3.5 (LTS) 3.1 7.0.0 7.2 5.5.31 8.0 9.3 5.5.31 10.5
3.6 3.1 7.0.0 7.3 5.6 8.0 9.4 10.0? 10.5
3.7 3.2 7.1.0 7.3 5.6 8.0 9.4 10.0? 10.5
3.8 3.2 7.1.0 7.4[4] 5.6 8.0 9.4 10.0? 10.5
3.9 (LTS) 3.5 7.2.0 7.4 5.6 8.0 9.5 10.2.29 10.5, 10.6 from 10.6.7
3.10 3.5 7.2.0 7.4 5.7 8.0 9.6 10.2.29 10.5, 10.6 from 10.6.7
3.11 3.6 7.3.0 8.0[5] 5.7 8.0 9.6 10.2.29 10.5, 10.6 from 10.6.7
4.0 3.6 7.3.0 8.0[5] 5.7 8.0 10 10.2.29 10.5, 10.6 from 10.6.7
4.1 (LTS) 3.9 7.4.0 8.1[6] 5.7 latest 12 10.4 latest
4.2[7] 3.11 8.0.0[8] 8.2[7] 8.0 latest 13 10.6.7 latest
4.3 3.11.8 8.0.0[8] 8.2 8.0 latest 13 10.6.7 latest

Footnotes:

  1. Release 1.6 was a de-facto LTS, supported for 3 years
  2. Release 1.9 was a de-facto LTS, supported for 6 years
  3. Upgrade from 1.9 to 2.x broke so many things, it is advisable to rebuild the site - either through course backups and restore or create courses from scratch making use of the numerous new features added since then
  4. PHP 7.4 since release 3.8.3. See MDL-66260.
  5. PHP 8.0 since Moodle 3.11.8 and 4.0.2. See MDL-70745.
  6. PHP 8.1 since Moodle 4.1.2. See MDL-73016.
  7. PHP 8.2 since Moodle 4.2.3. See MDL-76405
  8. 64 bit PHP only. See MDL-76405
